Hands on: I tried out the Scan 3XS GWP-ME A132C - read what I thought of this powerful workstation

Scan opts for the Intel route with its lower-priced system, as the 3XS GWP-ME A132C packs the best Intel CPU available in this class. Where other manufacturers chose the Core i9-13900K, Scan steps things up with the i9-13900KS. This incorporates eight P-cores with Hyper-Threading and 16 E-cores without, but the P-cores have a base frequency of 3.2GHz and 6GHz maximum boost, while the E-cores start at 2.4GHz and go up to 4.3GHz (although the latter is the same as the K variant).

Scan also takes advantage of the processor’s support for DDR5 memory by supplying 64GB of 5,600MHz RAM in the form of two 32GB DIMMs. This leaves two slots free for upgrade. The graphics choice is dependable, too: you can’t go wrong with Nvidia’s RTX A5000 handling 3D acceleration. Sporting 8,192 CUDA cores and 24GB of GDDR6 memory on a 256-bit bus providing 768GB/sec of bandwidth, the A5000 is a potent GPU.

The components of this workstation are built into a capacious Fractal Design Meshify 2 chassis, which offers lots of space for storage upgrades. Scan supplies only a single drive, but it’s a good one – a 2TB Corsair MP700 NVMe M.2 SSD, which supports PCI Express 5. According to testing with CrystalDiskMark 8.0.4, this drive provides sustained reading of 10,074MB/sec and writing at 10,190MB/sec, nearly 50% faster than the best PCI Express 4 NVMe SSDs. Only the Crucial T700 used by Armari this month is faster.

Despite its Core i9-13900KS CPU, the A132C came second to systems equipped with the K variant in the PC Pro benchmarks, although a score of 827 is still superb. Its Maxon Cinebench R23 CPU rendering result of 37,442 was also beaten by the Chillblast Apex Core i9 and Armari’s AMD Ryzen 9 7950X. However, the Blender CPU rendering time of 296 seconds beat other Intel-equipped workstations.

The RTX A5000 graphics delivered as expected with SPECviewperf 2020 v3.1 viewsets, showing competent scores for 3D animation, engineering and CAD. The excellent OpenCL result in LuxMark 3.1 of 15,287 was mirrored by a Blender GPU render time of just 143 seconds, although Armari’s AMD Radeon W7800 was faster, and the PCSpecialist Onyx Pro’s Nvidia GeForce RTX 4090 was in a different league entirely.

This is an excellent workstation for £4,500, and superb value when you consider its components, but it’s pipped to the top spot by Armari’s entry this month.
